YTMTOOLS Thread Rolling Machine for sale
  • Our factory was established in 1972. To create good thread rolling machines and thread rolling dies, we have kept om “Research” and “Development” continuously. “The best quality with inexpensive price”  is always the promise we give to the customers
  • Wire rolling length: Unlimited
  • 28 years of production experience
  • Through ISO9001 international quality system certification
  • Goods are all over 58 countries
Z28-150
Max rolling pressure:  180KN
Rolling spline range-Radial feed:  6-50mm
Rolling spline range-Axial feed:  6-42mm
Rolling die range-Max outer diameter:  120-170mm
Rolling die range-Aperture:  54mm
Rolling die range-Max width:  100mm
Main axis rotation:  36、47、60、78(r/min)
Main axis inclination:  ± 5°
Dimensions(L x W x H):  1600x1550x1455mm
weight:  1800kg±50kg
Z28-200
Max rolling pressure:  200KN
Rolling spline range-Radial feed:  60mm
Rolling spline range-Axial feed:  52mm
Rolling die range-Max outer diameter:  210mm
Rolling die range-Aperture:  75mm
Rolling die range-Max width:  120mm
Main axis rotation:  16、26、38、55、90(r/min)
Main axis inclination:  ± 12°
Dimensions(L x W x H):  1700x1850x1550mm
weight:  2300kg±50kg
Z28-500
Max rolling pressure:  500KN
Rolling spline range-Radial feed:  12-110mm
Rolling spline range-Axial feed:  12-80mm
Rolling die range-Max outer diameter:  240mm
Rolling die range-Aperture:  80mm
Rolling die range-Max width:  190mm
Main axis rotation:  16、26、38、55、90(r/min)
Main axis inclination:  ± 6°
Dimensions(L x W x H):  2600x2100x1600mm
weight:  4500kg±50kg
Z28-650
Max rolling pressure:  650KN
Rolling spline range-Radial feed:  120mm
Rolling spline range-Axial feed:  120mm
Rolling die range-Max outer diameter:  290mm
Rolling die range-Aperture:  100mm
Rolling die range-Max width:  200mm
Main axis rotation:  16、26、38、55、90(r/min)
Main axis inclination:  ± 8°
Dimensions(L x W x H):  2500x2700x1500mm
weight:  6100±50kg
WHY CHOOSE YTMTOOLS ?
Pre-sale Service
1.Supply item design,process design.
2.Help you to chose the fitest machine.
3.Making the machine according to your requirement.

Sale Service
1.Acceptance equipment together with you .
2.Help you to make the method statement and the details of the process.

After Service
1.Guarantee for a year.
2.Quality problem,we will sent you the accessories.
3.Free repair whole using life(without the freight and accessories charge.
4.Send you the easy broken part of rebar stirrup bending machine for free.

Are you a factory?
    Yes, we are. And we sincerely welcome to visit out factory at any time.

Do you have stock?
    Yes, within 3 days the machine willl be delivered if you have no special need. But because of the air pollution problem. You need to make a decision as soon as possible. In case of the price of raw material is uping.

Is the machine easy to operate?
    Yes, it is easy. Besides I will send videos to you, and let our engineer come to your country to help you if necessary
